The protection of sensitive measuring devices such as pressure transmitters, flow meters, and gauges becomes vital in wet steam pipelines and vapor processes. The condensate pot (or seal pot) is a crucial protection buffer that traps condensate and impurities before they reach the sensitive devices.
Condensate pots make sure that you have the same liquid head in impulse lines, which means no error in measurement due to pressure fluctuations or varying steam densities. Thus, selecting a reputed Condensate Pot Manufacturer in Bengalore guarantees your process control equipment functions accurately, has minimal downtime, and gives you a long service life.
A condensate pot is a compact yet heavy-duty pressure vessel installed between the main steam or gas line and the measuring instrument. Its primary job is to collect condensed liquid, vent trapped gases, and catch solid particles before they cause damage.
The manufacturer of industrial condensate pots is Pedlock, which manufactures the products according to international standards like ASME B31.1 and ASME B31.3. Any manufacturing unit is subjected to testing to verify pressure resistance and leak-proof performance prior to dispatching.
| Specification Parameter | Standard Technical Details |
|---|---|
| Pipe / Tube Sizes | 3 Inches, 4 Inches, and 6 Inches (Custom sizes available) |
| Pressure & Temp Rating | Up to 6,000 PSI @ Up to 250ºF |
| Inlet Connections | 1/2” (NPT / BSP / Socket Weld) |
| Outlet Connections | 1/2” (NPT / BSP / Socket Weld) |
| Drain Connections | 1/2” (NPT / BSP / Socket Weld) |
| Pot Connections | 1/2” (NPT / BSP / Socket Weld) |
| Material Options | Stainless Steel (SS 304, SS 316), Carbon Steel (CS), & Alloys |
| Quality Testing | Hydrostatic Pressure Testing & Pneumatic Testing |
The effectiveness of seal pots is determined by the choice of metal based on conditions of fluid type, temperature, and pressure :
When engaging with a reputed Condensate Pot Manufacturer in Bengalore, you can place orders for Condensate Pot products as per your specific schedule wall thicknesses (Schedule 40, 80, 160, or XXS) and port configurations as required by your pipeline setups.
Condensate pots are extensively utilized in different processing industries where accurate fluid measurements are needed:
Keep in mind a few points during the selection of the right unit for your piping arrangement.
Partnering with an established Condensate Pot Manufacturer in Bengalore ensures that your system receives fully tested, leak-proof components designed to eliminate plant shutdown risks.
