In modern process plants and industrial facilities, managing and distributing pneumatic supply safely, efficiently and with minimal pressure loss is critical to operational stability. Industrial compressed air systems often require a central point of control to route air to multiple downstream instruments without causing pressure drops or complex piping chaos. Ped Lock offers precision engineered Air Headers and Distribution Manifolds designed specifically to streamline compressed air supply from a single primary source to multiple pneumatic instruments, control valves, actuators and transmitters.
By replacing complex, cluttered piping networks and multiple individual valve assemblies with a compact, unified distribution header, Ped Lock ensures maximum energy efficiency, lower maintenance downtime and superior long term system reliability. As a premier Air Header valve manufacturer in Ahmedabad, we build heavy duty air headers engineered to meet stringent international standards for high pressure and critical industrial environments.
An Air Header (also commonly referred to as an Instrument Air Distribution Manifold or Fluid Distribution Header) serves as a robust centralized distribution hub in pneumatic supply networks. The system operates by accepting high pressure air from a main supply line or air compressor into a large capacity central pipe chamber. This central header chamber acts as a pressure equalizer, ensuring that air pressure remains stable across all connected equipment.
From this central chamber, compressed air is distributed uniformly through multiple take off outlet ports. Each individual outlet is equipped with its own dedicated isolation valve such as a high precision Needle Valve or Ball Valve allowing plant operators to isolate, service or adjust specific instrument lines without interrupting the main air supply or shutting down connected downstream processes.
Core Components of a Complete Air Header Assembly :
| Feature / Parameter | Specifications and Available Options |
|---|---|
| Pressure Rating | Up to 3,000 PSI / 6,000 PSI (210 bar / 413 bar) |
| Main Header Tube/Pipe Size | 2”, 3”, 4”, 6” (Custom sizes manufactured on order) |
| Inlet Connections | 1” 150# and 300# Class Flange / Screwed (NPT / BSPT) / Socket Weld |
| Outlet Connections | ¼” and ½” NPT / BSP (Female threads) |
| Drain Connections | ½” and 1” NPT / BSP with Drain Valve / Plug |
| Take off Isolation Valves | High precision Needle Valves or Ball Valves |
| Material Options | Stainless Steel (SS 304, SS 316, SS 316L), Carbon Steel (CS), Monel, Alloy Steel |
| Temperature Rating | PTFE Packing: Up to 232°C | Grafoil Packing: Up to 371°C |
| Mounting Provision | Standard 'U' Clamps and Mounting Hardware supplied |
Choosing the correct material for your air header assembly is essential to prevent internal corrosion, handle ambient temperature variations and extend equipment lifecycle. At Ped Lock, we source high grade raw materials certified for heavy industrial applications :
Ped Lock Air Headers are engineered for versatile deployment across diverse heavy industries and processing facilities :
To ensure leak proof operational safety in high pressure plant environments, every single Ped Lock Air Header undergoes rigorous testing procedures prior to dispatch :
Selecting the right valve and manifold manufacturer directly impacts your facility's safety, efficiency and maintenance costs. As a trusted Air Header valve manufacturer in ahmedabad, Ped Lock combines advanced manufacturing infrastructure, skilled engineering precision and strict compliance with global quality standards.
With over three decades of industry expertise, Ped Lock manufactures high performance valve assemblies, manifolds and tube fittings engineered to perform reliably under demanding conditions. Every air header is custom built to match your precise layout requirements, port counts, pressure ratings and mounting arrangements. Our dedicated technical team works closely with plant engineers to deliver customized solutions that streamline installation and optimize airflow performance across domestic and global industrial projects.
Upgrade your facility's pneumatic system with high durability, leak tested Air Headers from Ped Lock. Contact our engineering support team today to discuss your technical specifications, request a custom quote or obtain CAD drawings for your upcoming projects.
As a leading Air Header valve manufacturer in Ahmedabad, we offer fast turnaround times, competitive pricing and reliable technical support to help you build safer, more efficient fluid and air distribution networks.
